GIGABYTE Z690 AORUS PRO DDR4, LGA1700, Supports Intel 14th/13th/12th Gen

Experience the power and performance of the GIGABYTE Z690 AORUS PRO DDR4 motherboard, designed for enthusiasts who demand the best from their system. Featuring support for Intel 12th, 13th, and 14th Gen processors, this ATX motherboard delivers superior connectivity with PCIe 5.0, four ultra-fast PCIe 4.0 M.2 slots, and two USB 3.2 Gen 2×2 Type-C ports. Its robust 16+1+2 power delivery system with 90A power stages ensures stability under heavy loads, while the fully covered thermal design keeps components cool and efficient.

With onboard WiFi 6, 2.5GbE LAN, and RGB Fusion 2.0, the Z690 AORUS PRO is the ideal choice for gamers, streamers, and content creators looking for top-tier performance and style.

Key Features

• Processor Compatibility: Supports Intel 14th, 13th, and 12th Gen Core processors with the LGA1700 socket.
• Memory Support: Dual-channel DDR4 memory, up to 5600 MT/s (OC), with a maximum capacity of 128GB.
• PCIe 5.0: One x16 PCIe 5.0 slot for next-gen GPUs.
• Storage: Four PCIe 4.0 M.2 slots and six SATA 6Gb/s ports with RAID support.
• Networking: Intel 2.5GbE LAN and WiFi 6 for fast and reliable connections.
• Cooling: Fully covered MOSFET heatsinks, thermal guards for M.2 slots, and Smart Fan 6 technology.
• Audio: Hi-Fi audio with Realtek ALC4080 codec and WIMA capacitors for immersive sound.
• USB Connectivity: Rear USB 3.2 Gen 2×2 Type-C® and internal USB Type-C® header for modern devices.

GIGABYTE Z690 AORUS PRO Specifications

• Brand: GIGABYTE
• Model: Z690 AORUS PRO
• Socket Type: LGA1700
• Chipset: Intel® Z690 Express Chipset
• Processor Compatibility: Intel® 14th, 13th, and 12th Gen Core™, Pentium® Gold, and Celeron® processors.
• Memory Support: 4 x DDR4 DIMM slots, up to 128GB, speeds up to 5600 MT/s (OC).
• Graphics Support: 1 x DisplayPort 1.2 (4096×2304@60Hz).
• Expansion Slots: 1 x PCIe 5.0 x16 slot, 2 x PCIe 3.0 x4 slots.
• Storage Interface: 4 x PCIe 4.0 M.2 slots, 6 x SATA 6Gb/s connectors with RAID support (RAID 0, 1, 5, 10).
• Networking: Intel® 2.5GbE LAN, WiFi 6 (802.11ax) with Bluetooth 5.2.
• Audio: Realtek ALC4080 codec with WIMA capacitors, Hi-Fi sound, 7.1-channel digital output.
• USB Ports: Rear – 1 x USB 3.2 Gen 2×2 Type-C®, 4 x USB 3.2 Gen 2 Type-A, 4 x USB 3.2 Gen 1, 4 x USB 2.0. Front – 1 x USB 3.2 Gen 2×2 Type-C®, 1 x USB 3.2 Gen 1 header (2 ports), 2 x USB 2.0 headers (4 ports).
• Cooling Features: 1 x CPU fan header, 1 x water cooling CPU fan header, 4 x system fan headers, 2 x water pump headers.
• Internal I/O Connectors: 4 x M.2 connectors, 6 x SATA 6Gb/s connectors, RGB and addressable RGB LED headers.
• Back Panel I/O: 1 x USB 3.2 Gen 2×2 Type-C, 4 x USB 3.2 Gen 2 Type-A, 4 x USB 3.2 Gen 1, 4 x USB 2.0, 2 x SMA antenna connectors, 1 x DisplayPort, 1 x RJ-45 port, 1 x optical S/PDIF Out, 2 x audio jacks.
• BIOS: 256Mb Flash ROM, UEFI AMI BIOS.
• Operating System Support: Windows® 11 64-bit, Windows® 10 64-bit.
• Form Factor: ATX (30.5cm x 24.4cm).

Processor Compatibility

The GIGABYTE Z690 AORUS PRO supports Intel processors ranging from the 12th Gen (Alder Lake) to the latest 13th Gen (Raptor Lake) processors, thanks to its LGA1700 socket. This motherboard ensures robust performance and compatibility with multi-core processors for demanding workloads.

Whether you’re a gamer, creator, or multitasker, the Z690 chipset enables high-performance computing with Intel Turbo Boost Max Technology 3.0 and PCIe 5.0 capabilities.

Processor Recommendations for GIGABYTE Z690 AORUS PRO

• Intel Core i9-12900K: Outstanding for gamers and content creators seeking maximum performance.
• Intel Core i5-12600K: A cost-effective choice for smooth gaming and productivity tasks.

Discrete GPU Compatibility

The GIGABYTE Z690 AORUS PRO DDR4 motherboard features PCIe 5.0, which provides twice the bandwidth of PCIe 4.0. This future-proof technology allows the motherboard to fully unleash the power of next-gen GPUs.

Backward compatibility ensures that older PCIe 3.0 and 4.0 GPUs work seamlessly, but they will operate at their respective speeds. This ensures flexibility for users upgrading incrementally.

Graphics Card Recommendations for GIGABYTE Z690 AORUS PRO

• NVIDIA GeForce RTX 4080: Ideal for 4K gaming and demanding creative tasks.
• AMD Radeon RX 7900 XT: A powerhouse for high-end gaming and VR experiences.

Memory Compatibility

The GIGABYTE Z690 AORUS PRO DDR4 motherboard supports DDR4 memory, offering a balance of affordability and performance for users who want to maximize system efficiency. It features four DIMM slots, allowing a total capacity of up to 128GB. The motherboard supports dual-channel memory architecture for improved data bandwidth and system responsiveness.

In terms of speed, the board provides native DDR4 support up to 3200MHz, with overclocking capabilities reaching up to 5333MHz (OC) when paired with compatible high-performance memory modules. It is Intel XMP (Extreme Memory Profile) ready, enabling easy memory tuning for optimized performance.

While DDR5 is the latest standard, this motherboard is ideal for users who prefer proven DDR4 technology with lower latency and better compatibility with existing components. However, users should ensure memory compatibility by checking GIGABYTE’s QVL (Qualified Vendor List) for optimal stability and performance.

Power Requirements and Cooling

The GIGABYTE Z690 AORUS PRO DDR4 motherboard is equipped with dual 8-pin CPU power connectors to ensure stable and efficient power delivery, even during intense workloads or overclocking. The motherboard’s robust VRM cooling design includes enlarged heatsinks, thermal pads, and an aluminum backplate to manage heat effectively.

Additionally, multiple fan headers and an AIO pump header provide enhanced cooling flexibility, whether using air or liquid cooling solutions.

Recommended Power Supply for GIGABYTE Z690 AORUS PRO

• 750W PSU: Perfect for mid-range builds with GPUs like the RTX 3070 or RX 6700 XT.
• 850W+ PSU: Ideal for high-performance setups with GPUs like the RTX 4080 or RX 7900 XT.

Storage Options and Connectivity

The GIGABYTE Z690 AORUS PRO DDR4 motherboard features four PCIe 4.0 M.2 slots and six SATA 6Gb/s ports for ample storage flexibility. RAID 0, 1, 5, and 10 are supported for SATA devices, ensuring fast and reliable data access.

For connectivity, the motherboard includes Wi-Fi 6E, 2.5Gb Ethernet, USB 3.2 Gen 2×2, and USB Type-C, offering fast and stable networking and peripheral connections. These features make it a future-proof solution for gaming and productivity setups.

Is This Motherboard for You?

If you’re building a gaming PC, workstation, or content creation rig that requires top-tier performance, modern connectivity, and excellent cooling, the GIGABYTE Z690 AORUS PRO DDR4 Motherboard is an excellent choice.
