ASUS ROG STRIX B660-A GAMING WIFI, LGA1700, Intel 14th/13th/12th Gen

The ASUS ROG STRIX B660-A GAMING WIFI motherboard blends top-tier performance with stunning aesthetics. Designed to support Intel’s latest 14th, 13th, and 12th Gen processors, it features PCIe 5.0 and PCIe 4.0 slots, three M.2 slots with heatsinks, and DDR4 memory support up to 5333MHz (OC). With its 12+1 power stages, ProCool power connectors, and alloy chokes, it delivers efficient and reliable power for demanding gaming and multitasking setups.

Advanced features like AI Cooling, AI Networking, and Two-Way AI Noise Cancelation enhance your system’s performance and usability, while integrated WiFi 6 and Intel 2.5Gb Ethernet ensure blazing-fast connectivity. The motherboard also offers extensive personalization options with Aura Sync RGB lighting and a DIY-friendly design for easy installation.

Key Features

• Processor Compatibility: Supports Intel 14th, 13th, and 12th Gen Core, Pentium Gold, and Celeron processors.
• Memory Support: Four DDR4 DIMM slots with speeds up to 5333MHz (OC), supporting up to 128GB capacity.
• PCIe 5.0 Ready: One PCIe 5.0/4.0/3.0 x16 slot for the latest GPUs and expansion cards.
• Storage Options: Three M.2 PCIe 4.0 slots with heatsinks and four SATA 6Gb/s ports for ultra-fast storage.
• Networking: Intel WiFi 6 and 2.5Gb Ethernet for high-speed wired and wireless connectivity.
• Comprehensive Cooling: Features VRM heatsinks, integrated I/O cover, and AI Cooling for optimized thermal performance.
• Enhanced Audio: ROG SupremeFX ALC4080 audio codec with Savitech amplifier for immersive gaming audio.
• Customization Options: Aura Sync RGB lighting with three addressable Gen 2 headers and one RGB header.
• DIY-Friendly Design: Pre-mounted I/O shield, BIOS FlashBack™, M.2 Q-Latch, and Q-LED for easy installation and troubleshooting.

ASUS ROG STRIX B660-A GAMING WIFI Specifications

• Brand: ASUS
• Model: ROG STRIX B660-A GAMING WIFI D4
• Socket Type: LGA1700
• Chipset: Intel B660
• Processor Compatibility: 14th, 13th, and 12th Gen Intel Core, Pentium Gold, and Celeron processors
• Memory Support: 4 x DDR4 DIMM slots, up to 128GB, speeds up to 5333MHz (OC)
• Graphics Support: 1 x PCIe 5.0/4.0/3.0 x16 slot, 1 x PCIe 3.0 x16 slot (x4 mode), 2 x PCIe 3.0 x1 slots
• Storage Interface: 3 x M.2 PCIe 4.0 slots, 4 x SATA 6Gb/s connectors with RAID 0, 1, 5, and 10 support
• Networking: Intel WiFi 6 (802.11ax), Intel 2.5Gb Ethernet, Bluetooth 5.2
• Audio: ROG SupremeFX 7.1 HD Audio CODEC (ALC4080), 32-Bit/384kHz playback support
• USB Ports: Rear: 1 x USB 3.2 Gen 2×2 (Type-C), 1 x USB 3.2 Gen 2 (Type-A), 3 x USB 3.2 Gen 1 (2 x Type-A + 1 x Type-C), 4 x USB 2.0; Internal: 1 x USB 3.2 Gen 2 (Type-C), 1 x USB 3.2 Gen 1 header (2 ports), 2 x USB 2.0 headers (3 ports)
• Cooling: 1 x CPU fan header, 1 x CPU OPT fan header, 1 x AIO pump header, 3 x chassis fan headers, AI Cooling
• RGB Lighting: Aura Sync RGB lighting with 1 RGB header and 3 addressable Gen 2 headers
• Internal I/O Connectors: 3 x M.2 slots, 4 x SATA 6Gb/s connectors, USB headers, RGB headers, TPM header, Thunderbolt header, front panel audio header, clear CMOS header
• Back Panel I/O: 1 x HDMI 2.1, 1 x DisplayPort 1.4, 1 x USB 3.2 Gen 2×2 (Type-C), 1 x USB 3.2 Gen 2 (Type-A), 3 x USB 3.2 Gen 1, 4 x USB 2.0, 1 x Intel 2.5Gb Ethernet port, 1 x WiFi module, 5 x audio jacks, 1 x BIOS FlashBack™ button
• BIOS: 192Mb Flash ROM, UEFI AMI BIOS
• Form Factor: ATX (30.5cm x 24.4cm)
• Operating System Support: Windows 11 64-bit, Windows 10 64-bit

Processor Compatibility

The ASUS ROG STRIX B660-A GAMING WIFI motherboard supports Intel’s 12th and 13th Gen processors with its LGA1700 socket, delivering excellent performance and upgrade flexibility.

• Compatibility Range: From the affordable Pentium Gold and Celeron processors to powerful Core i9 CPUs, this motherboard adapts to various needs, whether for gaming, content creation, or productivity.
• Unlock the Potential: Enjoy enhanced performance with Intel Turbo Boost Technology 2.0 and PCIe 4.0 connectivity for maximum efficiency.

Processor Recommendations for ASUS ROG STRIX B660-A GAMING WIFI

• Intel Core i7-13700K: High performance for gaming and multitasking with excellent clock speeds.
• Intel Core i5-13400: Affordable option offering balanced power for gaming and everyday tasks.

Discrete GPU Compatibility

The ASUS ROG STRIX B660-A GAMING WIFI motherboard is equipped with a PCIe 4.0 x16 slot, ensuring optimal performance for modern graphics cards. However, PCIe 4.0 GPUs are preferred to avoid bandwidth limitations that might occur with PCIe 5.0 cards.

• Compatibility Note: Using a PCIe 5.0 GPU on a PCIe 4.0 slot will reduce the bandwidth to PCIe 4.0 speeds, but most modern GPUs like RTX 30/40 series and RX 6000 series work seamlessly without noticeable performance drops.

GPU Recommendations for ASUS ROG STRIX B660-A GAMING WIFI

• NVIDIA RTX 3060 Ti: Perfect for 1080p and 1440p gaming with great ray tracing capabilities.
• AMD Radeon RX 6700 XT: Excellent choice for budget 1440p performance with PCIe 4.0 compatibility.

Memory Compatibility

The ASUS ROG STRIX B660-A GAMING WIFI motherboard supports DDR5 memory, a major upgrade in speed and efficiency over DDR4.

• Capacity: Supports up to 128GB across 4 DIMM slots.
• Speeds: Native support for DDR5 4800 MT/s with overclocking capabilities reaching higher speeds depending on the memory kit.
• Intel XMP Support: Enables one-click memory overclocking for optimized performance.

While DDR5 allows faster speeds, overclocking stability can depend on the CPU’s memory controller and the quality of the RAM.

Power Requirements and Cooling

This ASUS ROG STRIX B660-A GAMING WIFI motherboard features robust power delivery with its 8+4-pin CPU power connectors, ensuring stability even under heavy loads or overclocking.

• VRM Cooling: Enhanced with large heatsinks to maintain VRM temperatures during demanding tasks like gaming or rendering.
• Fan and AIO Headers: Equipped with multiple 4-pin headers for system fans, CPU fans, and liquid cooling pumps, making it ideal for advanced cooling setups.

Power Supply Recommendations for ASUS ROG STRIX B660-A GAMING WIFI

• 750W PSU: Perfect for builds with GPUs like the RTX 3060 Ti or RX 6700 XT.
• 850W PSU: Recommended for more powerful setups using GPUs like the RTX 3080 or multi-device configurations.

Storage Options and Connectivity

The motherboard ensures fast and reliable storage options to match modern needs.

• M.2 Slots: Equipped with three PCIe 4.0 x4 M.2 slots for NVMe SSDs, enabling lightning-fast storage speeds for games, applications, and OS.
• SATA Ports: Includes 4 SATA III ports for traditional SSDs or HDDs, ideal for bulk storage solutions.
• Connectivity: Features Wi-Fi 6, Bluetooth 5.2, and 2.5Gb Ethernet, ensuring fast and stable networking for gaming or streaming.

Is This Motherboard for You?

The ASUS ROG STRIX B660-A GAMING WIFI motherboard is ideal for gamers, content creators, and PC enthusiasts seeking a high-performance, feature-rich motherboard. With PCIe 5.0, advanced cooling, WiFi 6, and customizable RGB lighting, it’s a top-tier choice for modern and future-proof gaming builds.
