GIGABYTE B660M AORUS PRO AX, LGA1700, Intel 14th/13th/12th Gen

The GIGABYTE B660M AORUS PRO AX motherboard is a powerful and versatile board that offers exceptional performance for high-demand workloads, gaming, and content creation. Built on the Intel B660 chipset, this micro-ATX motherboard supports 14th, 13th, and 12th Gen Intel Core processors, delivering robust power with a 12+1+1 Twin Hybrid Digital VRM design featuring 60A DrMOS.

Equipped with dual PCIe 4.0 M.2 slots with Thermal Guard for ultra-fast storage, blazing-fast Intel 2.5GbE LAN, and WiFi 6 with Bluetooth 5.2, the GIGABYTE B660M AORUS PRO AX ensures seamless connectivity. Its fully covered thermal design, Smart Fan 6 technology, and integrated RGB Fusion 2.0 lighting provide the ideal balance of performance, cooling, and aesthetics.

DIY-friendly features, such as a pre-installed I/O shield, Q-Flash Plus for BIOS updates without components, and enhanced build durability, make it an excellent choice for your next Intel build.

Key Features

• Processor Compatibility: Supports Intel 14th, 13th, and 12th Gen Core, Pentium Gold, and Celeron processors.
• Memory Support: Four DDR4 DIMM slots with speeds up to 5333 MT/s (OC), supporting up to 128GB of system memory.
• Dual PCIe 4.0 M.2 Slots: Ultra-fast storage with Thermal Guards to maintain optimal performance.
• Premium Networking: Intel 2.5GbE LAN and WiFi 6 for high-speed, low-latency connectivity.
• Optimized Cooling: Fully covered thermal design with heatsinks, Smart Fan 6, and hybrid fan headers.
• Customizable RGB Lighting: RGB Fusion 2.0 with support for addressable and standard RGB LED strips.
• USB 3.2 Gen 2×2 Connectivity: SuperSpeed USB Type-C® ports for lightning-fast 20Gb/s data transfer.
• Durable Design: 12+1+1 Twin Hybrid Digital VRM with premium components ensures stable power delivery.
• DIY-Friendly: Pre-installed I/O shield, Q-Flash Plus for easy BIOS updates, and intuitive app support.

GIGABYTE B660M AORUS PRO AX Specifications

• Brand: GIGABYTE
• Model: B660M AORUS PRO AX
• Socket Type: LGA1700
• Chipset: Intel B660
• Processor Compatibility: Intel 14th, 13th, and 12th Gen Core, Pentium Gold, and Celeron processors
• Memory Support: 4 x DDR4 DIMM slots, up to 128GB, speeds up to 5333 MT/s (OC)
• Graphics Support: 1 x HDMI 2.1 (4096×2160@60Hz), 1 x DisplayPort 1.2 (4096×2304@60Hz)
• Expansion Slots: 1 x PCIe 4.0 x16 slot, 1 x PCIe 3.0 x16 slot (x4 mode)
• Storage Interface: 2 x PCIe 4.0 x4 M.2 slots with Thermal Guards, 4 x SATA 6Gb/s connectors with RAID 0, 1, 5, and 10 support
• Networking: Intel 2.5GbE LAN, WiFi 6 (802.11ax) with Bluetooth 5.2
• Audio: Realtek HD Audio with 7.1-channel support, S/PDIF Out, and Noise Guard
• USB Ports (Rear): 1 x USB 3.2 Gen 2×2 Type-C®, 1 x USB 3.2 Gen 2 Type-A, 4 x USB 3.2 Gen 1, 4 x USB 2.0
• USB Ports (Front): 1 x USB 3.2 Gen 2 Type-C® header, 1 x USB 3.2 Gen 1 header (2 ports), 2 x USB 2.0 headers (4 ports)
• Cooling: 1 x CPU fan header, 1 x water cooling CPU fan header, 3 x system fan headers, 1 x pump header
• Internal I/O Connectors: 2 x M.2 connectors, 4 x SATA 6Gb/s connectors, Addressable RGB and standard RGB LED headers
• Back Panel I/O: 1 x HDMI 2.1, 1 x DisplayPort 1.2, 1 x USB 3.2 Gen 2×2 Type-C®, 4 x USB 3.2 Gen 1, 4 x USB 2.0, 1 x RJ-45 LAN port, 2 x SMA antenna connectors (WiFi), 3 x audio jacks, 1 x S/PDIF Out
• BIOS: 256Mb Flash ROM, UEFI AMI BIOS
• Operating System Support: Windows 11 64-bit, Windows 10 64-bit
• Form Factor: Micro-ATX (24.4cm x 24.4cm)

Processor Compatibility

The GIGABYTE B660M AORUS PRO AX supports a range of Intel processors, providing versatility for builds from budget to high-end:

• 10th Gen Intel Processors: While not supported on the LGA 1700 socket, consider upgrading to a newer gen for better performance.
• 12th Gen Intel Alder Lake CPUs: Fully supported, including Core i3, i5, i7, and i9 processors. This generation introduced hybrid architecture for improved multitasking.
• 13th Gen Intel Raptor Lake CPUs: Supported with BIOS updates, offering exceptional performance and efficiency with up to 24 cores on high-end models.

Recommended Processors for GIGABYTE B660M AORUS PRO AX

• Intel Core i5-12400F: Great value for gaming and productivity without integrated graphics.
• Intel Core i7-13700K: High performance for creators and gamers looking for excellent multitasking power.

Discrete GPU Compatibility

The motherboard features a PCIe 4.0 x16 slot, which delivers excellent compatibility with modern GPUs. However, it does not support PCIe 5.0, which may limit the bandwidth for future high-end graphics cards. While PCIe 4.0 is sufficient for most GPUs today, those with PCIe 5.0 GPUs will still work but may not utilize their full potential.

Recommended Graphics Cards for GIGABYTE B660M AORUS PRO AX

• NVIDIA RTX 3060 Ti: Ideal for 1080p and 1440p gaming with ray tracing enabled.
• AMD Radeon RX 6700 XT: Offers excellent performance for gaming and content creation at an affordable price.

Memory Compatibility

The GIGABYTE B660M AORUS PRO AX supports DDR4 memory with a maximum capacity of 128GB across 4 DIMM slots. It offers support for overclocked speeds of up to 5333MHz with Intel XMP profiles.

However, overclocking potential may vary depending on the quality of the memory modules and the processor used.

Power Requirements and Cooling

The motherboard is equipped with a 24-pin ATX power connector and an 8-pin CPU power connector, ensuring stable power delivery to support Intel’s high-performance CPUs.

For cooling, the board features:

• Multiple fan headers, including a dedicated CPU fan header, system fan headers, and an AIO pump header for liquid cooling setups.
• A robust VRM heatsink that efficiently dissipates heat, ensuring stable performance under heavy workloads.

Recommended Power Supply for GIGABYTE B660M AORUS PRO AX

• 650W PSU: Ideal for builds with mid-range GPUs like the RTX 3060 Ti.
• 750W PSU: Recommended for high-performance GPUs like the RTX 3070 or Radeon RX 6700 XT.

Storage Options and Connectivity

The GIGABYTE B660M AORUS PRO AX provides a wide range of storage and connectivity options:

• Storage: Features dual PCIe 4.0 M.2 slots for high-speed NVMe SSDs and four SATA III ports for traditional storage drives.
• Connectivity: Includes Wi-Fi 6 for fast wireless networking, Realtek 2.5Gb Ethernet for high-speed wired connections, and multiple USB ports, including USB 3.2 Gen 2×2 for ultra-fast data transfer.

This compact and performance-focused motherboard is ideal for gamers, creators, and professionals seeking a reliable solution for their Intel 12th and 13th Gen processors.

Is This Motherboard for You?

The GIGABYTE B660M AORUS PRO AX is an excellent choice for gamers, creators, and PC enthusiasts seeking a compact yet powerful motherboard. Its robust power delivery, fast storage options, premium networking, and customizable lighting make it an ideal foundation for modern Intel builds.
