GIGABYTE Z690 AORUS ELITE AX, LGA1700, Supports Intel 14th/13th/12th Gen

Unleash the full potential of Intel’s 12th, 13th, and 14th Gen processors with the GIGABYTE Z690 AORUS ELITE AX motherboard. This ATX motherboard boasts advanced features such as PCIe 5.0, a 16+1+2 power phase design with 70A power stages, and fully covered thermal designs to ensure unparalleled stability and performance. With four PCIe 4.0 M.2 slots, WiFi 6, and 2.5GbE LAN, it caters to gamers, creators, and power users alike.

Enjoy DIY-friendly features like Q-Flash Plus for updating BIOS without components, and customizable RGB Fusion 2.0 lighting to make your build stand out. The AORUS ELITE AX is built for high-performance, ensuring it keeps up with the most demanding gaming and productivity workloads.

Key Features

• Processor Compatibility: Supports Intel 14th, 13th, and 12th Gen Core, Pentium Gold, and Celeron processors.
• Memory Support: Dual-channel DDR4 with speeds up to 5333 MT/s (OC) and 128GB capacity.
• PCIe 5.0: One PCIe 5.0 x16 slot for next-generation GPUs.
• Storage: Four PCIe 4.0 M.2 slots and six SATA 6Gb/s ports with RAID support.
• Networking: Intel 2.5GbE LAN and WiFi 6 (802.11ax) for fast, stable connections.
• Cooling: Fully covered MOSFET heatsinks, M.2 thermal guards, and Smart Fan 6 technology.
• Audio: Realtek ALC1220-VB audio codec with WIMA capacitors for immersive sound quality.
• USB Connectivity: Rear USB 3.2 Gen 2×2 Type-C® and additional internal USB headers.

GIGABYTE Z690 AORUS ELITE AX Specifications

• Brand: GIGABYTE
• Model: Z690 AORUS ELITE AX
• Socket Type: LGA1700
• Chipset: Intel Z690
• Processor Compatibility: Intel 14th, 13th, and 12th Gen Core, Pentium Gold, and Celeron processors.
• Memory Support: 4 x DDR4 DIMM slots, up to 128GB, speeds up to 5333 MT/s (OC).
• Graphics Support: 1 x HDMI 2.1 port (4096×2160@60Hz), 1 x DisplayPort 1.2 (4096×2304@60Hz).
• Expansion Slots: 1 x PCIe 5.0 x16 slot, 2 x PCIe 3.0 x4 slots.
• Storage Interface: 4 x PCIe 4.0 M.2 slots, 6 x SATA 6Gb/s connectors with RAID 0, 1, 5, 10 support.
• Networking: Intel 2.5GbE LAN, WiFi 6 (802.11ax) with Bluetooth 5.2.
• Audio: Realtek ALC1220-VB with WIMA capacitors, 7.1-channel support, S/PDIF Out.
• USB Ports: Rear – 1 x USB 3.2 Gen 2×2 Type-C®, 2 x USB 3.2 Gen 2 Type-A, 3 x USB 3.2 Gen 1, 4 x USB 2.0. Front – 1 x USB 3.2 Gen 2 Type-C®, 1 x USB 3.2 Gen 1 header (2 ports), 2 x USB 2.0 headers (4 ports).
• Cooling Features: 1 x CPU fan header, 1 x water cooling CPU fan header, 3 x system fan headers, 1 x pump header.
• Internal I/O Connectors: 4 x M.2 connectors, 6 x SATA 6Gb/s connectors, RGB and addressable RGB LED headers.
• Back Panel I/O: 1 x USB 3.2 Gen 2×2 Type-C®, 2 x USB 3.2 Gen 2 Type-A, 3 x USB 3.2 Gen 1, 4 x USB 2.0, 2 x SMA antenna connectors, 1 x HDMI port, 1 x DisplayPort, 1 x RJ-45 port, 1 x optical S/PDIF Out, 2 x audio jacks.
• BIOS: 256Mb Flash ROM, UEFI AMI BIOS.
• Operating System Support: Windows 11 64-bit, Windows 10 64-bit.
• Form Factor: ATX (30.5cm x 24.4cm).

Processor Compatibility

The GIGABYTE Z690 AORUS ELITE AX motherboard offers extensive processor compatibility, making it a future-ready choice for builders. It supports:

• Intel 12th Gen Processors (Alder Lake): Entry-level CPUs like the Intel Pentium Gold G7400 are perfect for basic tasks.
• Intel 13th Gen Processors (Raptor Lake): Handles high-end CPUs like the Intel Core i9-13900K for demanding workloads.

The motherboard uses the LGA 1700 socket, ensuring seamless integration with Intel’s 12th and 13th Gen processors. With BIOS updates, it may support potential future Intel generations.

Processor Recommendations GIGABYTE Z690 AORUS ELITE AX

• For Budget Builds: Intel Core i5-12400 – Affordable and powerful for gaming and multitasking.
• For High-Performance Builds: Intel Core i7-13700K – Exceptional for gaming, streaming, and heavy workloads.

Discrete GPU Compatibility

The GIGABYTE Z690 AORUS ELITE AX motherboard features a PCIe 5.0 x16 slot, offering blazing-fast performance for the latest GPUs. It ensures full compatibility with PCIe 5.0 cards, delivering faster data transfer rates and better efficiency.

For GPUs using PCIe 4.0 or PCIe 3.0, this motherboard maintains backward compatibility. However, older GPUs may not fully utilize the PCIe 5.0 bandwidth, which could limit future-proofing.

Graphics Card Recommendations for GIGABYTE Z690 AORUS ELITE AX

• For 1080p Gaming: NVIDIA GeForce RTX 4060 – Delivers excellent performance for mid-range gaming.
• For 4K Gaming and Creation: AMD Radeon RX 7900 XTX – Perfect for high-resolution gaming and content creation.

Memory Compatibility

The Gigabyte Z690 AORUS ELITE AX motherboard supports DDR5 memory, enabling blazing-fast data transfer speeds and increased bandwidth. Key features include:

• Up to 128GB of Memory Capacity: With 4 DIMM slots, this motherboard can handle memory-intensive applications.
• Overclocking Support: With Intel XMP profiles, achieve memory speeds of up to 6400+ MHz for maximum performance.

However, DDR5 overclocking requires compatible RAM kits, and system stability depends on the processor and memory combination.

Power Requirements and Cooling

This motherboard ensures stable power delivery and cooling, making it suitable for demanding systems. Key features include:

• Power Connectors: Equipped with an 8+4 pin ATX power connector for robust and efficient power delivery, especially during overclocking.
• Cooling Headers: Includes multiple 4-pin fan headers and a dedicated AIO pump header for liquid cooling setups.
• VRM Cooling: Features robust heatsinks and thermal padding to ensure efficient cooling for VRMs, even under heavy workloads.

Recommended Power Supply for Gigabyte Z690 AORUS ELITE AX

• For Mid-Range Builds: 650W PSU – Ideal for systems with GPUs like the RTX 4060.
• For High-End Builds: 850W PSU – Perfect for overclocked CPUs and GPUs like the RTX 4080.

Storage Options and Connectivity

The GIGABYTE Z690 AORUS ELITE AX motherboard offers versatile storage and connectivity options:

• M.2 Slots: Supports up to 4 PCIe 4.0 NVMe SSDs for high-speed storage.
• SATA Ports: Includes 6 SATA III ports for HDDs and SATA SSDs.
• USB Ports: Features USB 3.2 Gen 2×2, USB Type-C, and legacy USB ports for flexible connectivity.
• Networking: Built-in Wi-Fi 6E and 2.5Gbps Ethernet for ultra-fast, reliable network performance.

Is This Motherboard for You?

If you’re looking for a high-performance ATX motherboard with premium features like PCIe 5.0, WiFi 6, advanced cooling, and robust power delivery, the GIGABYTE Z690 AORUS ELITE AX motherboard is the perfect choice.

Whether you’re a gamer, creator, or power user, this motherboard has everything you need for a future-proof PC build.
